Kích cỡ | Tất cả
| AC Power Supply | 110Vac ±10% 230Vac ±10% |
|
| Nominal Current (RMS) at 50°C | 8A 12A 16A 20A |
|
| Frequency | 50Hz 60Hz |
|
| Motor Connection | 1 | |
| Control Technology | analog | |
| Motor control type | phase cutting | |
| Case IP Grade | IP55 IP00 |
|
| Conforms to the following standards | Standard EN 61800-3 (directive 2004/108 CE) Standard EN 50178 (directive 2006/95 CE) Standard EN 60204-1 (directive 2006/95 CE) Connectable into IT-TT-TN systems |
|
| Display and settings | rotary switches with 13 stable positions signaling leds |
|
| Control Function | proportional master (P) slave |
|
| Number of working parameter set | 1 2 |
|
| Control Parameters | set-point 2 set-point on request minimum speed limit cut-off maximum speed limit |
|
| Special Features | direct / reverse mode selection | |
| commands analog input | 4 | |
| Analog input type | 4-20mA 0-5Vdc 0-10Vdc NTC 10KOhm 25°C |
|
| Transducer type | 4...20mA 0°C...+70°C 0,5...4,5Vdc |
|
| ON/OFF inputs number | 1 | |
| Logic inputs working modes | (SP) second set-point | |
| Auxiliary power supply | 5,0 Volt (Vrr) stabilized 10,0 Volt (Vrr) stabilized 20-24 Volt ±10% |
|
| 0-10Vdc programmable analog outputs | 1 | |
| Slave type PWM Command | 1 | |
| Protections | power supply overvoltages transient suppressors on analog signal overcurrent protection on current signal input lines insulated from power supply voltage |
|
| Work temperature | -10°C...+50°C | |
| Storage temperature | -20°C...+80°C |
